Frame Relay configuration task list 182

SmartWare Software Configuration Guide 15 • Frame Relay configuration

Enabling a Frame Relay PVC

After binding Framerelay PVC to an ip interface it must be enabled for packet processing. This procedure acti-

vates the PVC by opening the bound ip interface.

This procedure describes how to enable Framerelay PVC for packet processing

Mode: PVC

Example: Disabling a Frame Relay PVC

The following example enables Frame Relay PVC with the DLCI 1 on the serial interface on slot 0 and port 0.

node(cfg)#port serial 0 0

node(prt-ser)[0/0]#framerelay

node(frm-rel)[0/0]#pvc 1

node(pvc)[1]#no shutdown

Check the PVC 1 status using show running-conﬁg and verify that the entry no shutdown occurs in the con-

ﬁguration part responsible for this PVC.

node(pvc)[1]#show running-config

Running configuration:

#----------------------------------------------------------------#

# #

…

pvc 1

encapsulation rfc1490

bind interface wan router

no shutdown

Disabling a Frame Relay PVC

Frame Relay PVCs can be disabled whenever it is necessary. Be aware that disabling a speciﬁc PVC also disables

the related serial interface and vice versa.

This procedure describes how to disable the Frame Relay PVC DLCI on the serial interface.

Mode: PVC

Example: Disabling a Frame Relay PVC

The following example disables Frame Relay PVC 1 on the serial interface on slot 0 and port 0.

node(cfg)#port serial 0 0

node(prt-ser)[0/0]#framerelay

node(frm-rel)[0/0]#pvc 1

Step Command Purpose

1 node(pvc)[dlci]#no shutdown Enables the Frame Relay PVC

Step Command Purpose

1 node(pvc)[dlci]#shutdown Disables the Frame Relay PVC DLCI.
