ISDN configuration task list 221
SmartWare Software Configuration Guide 19 • ISDN configuration
Mode: Operator execution
ISDN Configuration Examples
Example: Configuring BRI port as Euro-ISDN interface
The following example shows how to configure port 0/0 as a Euro ISDN interface with user side signaling.
172.16.40.71(cfg)#port bri 0 0
172.16.40.71(prt-bri)[0/0]#q921
172.16.40.71(q921)[0/0]#q931
172.16.40.71(q931)[0/0]#uni-side user
172.16.40.71(q931)[0/0]#encapsulation cc-isdn
172.16.40.71(q931)[0/0]#bind interface bri00
172.16.40.71(q931)[0/0]#exit
172.16.40.71(q921)[0/0]#exit
172.16.40.71(prt-bri)[0/0]#no shutdown
Example: being clock slave on uni network interface
The following example shows how to configure both ports of a SmartNode with network signaling but receive
the clock (via port 0) from the peer. The peer must be configured accordingly, i.e. port 0 as USR/clock master
and port 1 NET/clock slave.
172.16.40.71(cfg)#port bri 0 0
172.16.40.71(prt-bri)[0/0]#clock slave
172.16.40.71(prt-bri)[0/0]#q921
172.16.40.71(q921)[0/0]#q931
172.16.40.71(q931)[0/0]#uni-side net
172.16.40.71(q931)[0/0]#encapsulation cc-isdn
172.16.40.71(q931)[0/0]#bind interface bri00
172.16.40.71(q931)[0/0]#exit
172.16.40.71(q921)[0/0]#exit
172.16.40.71(prt-bri)[0/0]#no shutdown
172.16.40.71(cfg)#port bri 0 1
172.16.40.71(prt-bri)[0/0]#q921
172.16.40.71(q921)[0/0]#q931
172.16.40.71(q931)[0/0]#uni-side net
172.16.40.71(q931)[0/0]#encapsulation cc-isdn
172.16.40.71(q931)[0/0]#bind interface bri01
172.16.40.71(q931)[0/0]#exit
172.16.40.71(q921)[0/0]#exit
172.16.40.71(prt-bri)[0/0]#no shutdown
Step Command Purpose
1 node#show port isdn [slot port] [detail <-
level>]
Show the status of one or more ISDN ports.
If the optional arguments slot/port are omitted the
status of all ISDN ports is displayed.
Level could be 1 to 5. Level 1 shows less, level 5
shows all available information. Default level is 3.
