Pentax K100D User Manual

76700 -7/94-
(3) FRONT HOUSING BLOCK....................................................................................... 32
(4) 0-Q200 (FLASH PC BOARD, A15 AND A15)............................................................ 32
(5) A6 (LEFT SHOULDER PLATE)................................................................................ 33
(6) T901 (LOWER FLEX BOARD).................................................................................. 33
(7) 0-A3 (BOTTOM PLATE ASSY).................................................................................. 34
(8) T200 (UPPER FLEX BLOCK)................................................................................... 34
(9) LCD BLOCK............................................................................................................... 35
(10) [CONFIRM] CCD BASE PLATE SUPPORT PILLAR...............................................
36
(11) 0-C000.................................................................. 37
(12) 0-T100 (MAIN PC BOARD)...................................................................................... 38
(13) [CONFIRM] FUNCTION CHECK 1...........................................................................
40
13-1. PREPARATION...................................................................................................... 40
13-2. POWER SUPPLY CHECK..................................................................................... 40
13-3. WRITING FIRMWARE.......................................................................................... 41
13-4 INITIALIZATION OF DATA 41
13-5. SETTING TEST MODE......................................................................................... 41
13-6. SHUTTER RELEASE AND EXPOSURE.............................................................. 42
13-7. AF FUNCTION....................................................................................................... 42
13-8.CANCELLATION OF TEST MODE 42
(14) SR ADJUSTMENT I (UNIT ADJUSTMENT)
43
14-1 SETTING THE COMPUTER 43
14-2 PREPARATION 43
14-3 ADJUSTMENT ITEMS 43
14-4 ADJUSTMENT PROCEDURE 44
14-5 END PROCEDURE 46
14-6 RESET TEST MODE 46
(15) A150 (FRONT COVER) 47
(16) A201 (REAR COVER)............................................................................................ 47
(17) [ADJUST] POSITIONING 0-J100..............................................................................
49
(18) 0-A301 (TOP COVER).............................................................................................. 50
(19) A161 (SIDE COVER) 51
(20) [CONFIRM] FUNCTION CHECK 2...........................................................................
52
20-1. PREPARATION...................................................................................................... 52
20-2. BATTERY CONSUMPTION CURRENT CHECK................................................ 52
20-3. AF AND SI FUNCTION CHECK........................................................................... 52
20-4. EXPOSURE MODE AND SHUTTER RELEASE................................................. 52
20-5. SWITCH TEST (EACH SW AND CONNTACT OF DIAL)................................... 53
20-6. SHOOTING AND PLAYBACK FUNCTION......................................................... 54
20-7. FLASH FUNCTION CHECK................................................................................. 54
20-8. [ADJUST] FLASH STORE POSITION.....................................................................
54
20-9 [ADJUST] SI-LED POSITION
55
20-10. APERTURE CONTROL CHECK AND SURFACE OF CCD CHECK.................. 55

Pentax K100D Specifications

General

Megapixel	6.1 MP
Sensor type	CCD
Interface	USB 2.0
Color depth	8 bit
Digital SLR	Yes
Video capability	No
Camera shutter speed	1/4000 - 30 s
Focus	TTL
Auto focusing (AF) modes	centre weighted auto focus, continuous auto focus, selective auto focus
Light metering	Centre-weighted, Spot
ISO sensitivity	200, 400, 800, 1600, 3200, Auto
Light exposure modes	aperture priority AE, auto, shutter priority AE
Compatible memory cards	sd
Display diagonal	2.5 \
Display resolution (numeric)	210000 pixels
Magnification	0.85X x
I/O ports	AV - NTSC/PAL
USB version	2.0
Product color	Black
Battery type	AA
Number of batteries supported	4
Flash modes	auto, Flash off, Red-eye reduction
Scene modes	beach, Candlelight, Children, Close-up (macro), Documents, Museum, Night, Night portrait, Portrait, Sunset, Landscape (scenery)
Photo effects	black&white, Sepia
White balance	Cloudy, daylight, flash, Fluorescent, manual, Shade, Tungsten
Camera shutter type	Electronic

Weight and Dimensions

Depth	70 mm
Width	129.5 mm
Height	92.5 mm
Weight	570 g
