Getting Started
Adjusting the Viewfinder Diopter
Adjust the viewfinder to suit your eyesight.
If it is difficult to see the viewfinder image clearly, slide the diopter
adjustment lever sideways.
You can adjust the diopter from –2.5m
-1
to +1.5m
-1
.
1
Look through the viewfinder
and point the camera at a white
wall or other bright and
consistent surface. Slide the
diopter adjustment lever left or
right.
Adjust the lever until the AF frame in
the viewfinder is focused.
•The FP Eyecup is attached to the
viewfinder portion when camera leaves
the factory. Diopter adjustment is
available with the F
P Eyecup attached.
However, adjustment is easier with the
eyecup removed. To remove the FP
Eyecup, press in one side and pull it out in
the direction of the arrow.
To attach the F
P Eyecup, align it with the
groove on the viewfinder eyepiece and
push it into position.
• If it is difficult to see the viewfinder image clearly even if you set the diopter
adjustment lever, use the diopter correction lens adapter M. However, the
eyecup must be removed to use this adapter. (p.216)
AF frame
