Peri CB 240 - Introduction; Overview, Main Components

1
Overview, Main Components
CB 240 Climbing Formwork
Instructions for Assembly and Use – Standard Configuration
Introduction
Concreting platform
Concreting height h
B
Formwork height h
s
Intermediate platform
Working platform
Finishing platform
9
7
6
11
1
8
3
4
10
5
5
2
Climbing Formwork CB 240 with
VARIO GT 24 Girder Wall Formwork
– Concreting height 5.40 m.
– Extended suspension of finishing
platform.
– Tension Anchor CB with DW 15 as
wind bracing.
– Intermediate platform on formwork.
*Formwork height =
concreting height + formwork projection
(max. 5.40 m)
