CB 240 Climbing Formwork
Instructions for Assembly and Use – Standard Configuration
Introduction
Dimension Specifications
Dimensions are usually given in mm and
m. Other measurement units, e.g. cm,
are shown in the drawings.
Conventions
– Instructions are numbered
(1. ....., 2. ....., 3. .....)
Multiple position numbers, i.e. alternative
components, are represented with a
slash: 1 / 2.
Arrows
Actions
Forces
Key
General
The illustration on the front cover of
these instructions is understood to be a
system representation only. The assem-
bly steps presented in these Instructions
for Assembly and Use are shown in the
form of examples with only one compo-
nent size. They are valid for all component
sizes contained in the standard configu-
ration accordingly.
In order to ensure better understandibility,
detailed descriptions are partly incom-
plete. The safety installations which have
possibly not been shown in these de-
tailed descriptions must nevertheless be
available. Preceding working steps must
be complied with.
Safety Instructions
Visual Check
Load-bearing point
Personal protective equipment
to prevent falling from a height
(PPE)
Warning of suspended load
Note
Tip
