CB 240 Climbing Formwork
72
Item no. Weight kg
051090 13.500 Connector TRIO-CB
For fixing TRIO panels to the Strongback CB. Used
on horizontal or vertical struts. With integrated
height adjustment.
Complete with
1 pc. 715936 Pin Ø 25 x 180, incl. dowel pin Ø 6
1 pc. 018060 Cotter Pin 4/1, galv.
1
0
0
4
0
0
8
2
1
8
0
Ø25
415
SW 19
051110 25.200 Adjustable Brace CB 164-224
For aligning the Strongback CB.
Complete with
2 pc. 715936 Pin Ø 25 x 180, incl. dowel pin Ø 6
2 pc. 018060 Cotter Pin 4/1, galv.
1580
min 1640 max 2240
8
9
Ø
051030 5.320 Height Adjusting Unit CB, SCS
For height adjustment of VARIO GT 24 panels on
the Strongbacks CB and SCS.
Complete with
1 pc. 715936 Pin Ø 25 x 180, incl. dowel pin Ø 6
1 pc. 018060 Cotter Pin 4/1, galv.
2
4
0
60 55
82
190
m
a
x
1
8
2
Ø25
SW 19
