CB 240 Climbing Formwork
79
Item no. Weight kg
051610 6.940 Side Guardrail Post CB
For assembly of an end guardrail. Bolted to the
platform main beam.
4
4
0
5
0
4
4
0
1
2
7
0
10050
Ø9
Ø7
4
0
1
9
0
390
051640 0.014
Accessories
Lag Screw DIN 571 6 x 80, galv.
051160 0.894 Guardrail Connector CB
For assembling scaffold tubes on handrail posts.
9
5
60
9
Ø48
SW 19
126228 0.030
Accessories
F.H. Bolt DIN 603 M8 x 70 MU, galv.
