Advanced Seat Operation through R-net Control Panel
2
Normal
PROFILE
MODE
Press Mode Button to access Seat Menu
Recalling a Seat Position from Memory
Seat Position Memories can be recalled using
the Joystick in the Control Panel that operates
the wheelchair drive motors. The Seat Position
Memories are part of the Seating Control Mode.
Seating Control Mode is accessed via the MODE
button on the Control Panel. Press and release the
MODE button until the seating system icon appears
in the LCD display.
Once the Seating System Icon appears on the
LCD display, push the joystick left or right to
select the memory location you wish to recall.
The memory recall icons are “after” the regular
seat function icons.
M1 M2 M3
Memory Position 1
Memory Position 2 Memory Position 3
NOTE: Memory Recall through the R-net JSM must be enabled via Wheelchair Builder before memory
can be accessed using the R-net Joystick Module.
Once the desired memory location is displayed
on the LCD (Memory 2 in this example), push
the joystick forward to move the seat to the
memorized position.
When actuator movement stops, the seating
system has reached the stored position.
M1
M2
M3
Push the joystick forward to move the seat
to the memorized position.
