Permobil ICS - Standing Function (VS Seat); Standing Operation via Switchbox

18
Standing Function
(Only applies to VS Seat)
The VS Seating System is capable of transitioning
from a seated or partially reclined position to a fully
standing position via the use of an ICS Switchbox
button or through the Control Panel.
Standing Operation through Switchbox
Using the ICS Switchbox to operate the Standing
Sequence with Layout 2:
• Switch 1 will move the Standing Sequence UP
(to Stand the Chair)
• Switch 5 will move the Standing Sequence
DOWN (to unStand the Chair)
For clarity, LEDs for other switches are not shown
in this example.
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
Using the ICS Switchbox to operate the Standing
Sequence with Layout 3:
• Switch 1 will move the Standing Sequence UP
(to Stand the Chair)
• Switch 5 will move the Standing Sequence
DOWN (to unStand the Chair)
For clarity, LEDs for other switches are not shown
in this example.
LED
Off
LED
Off
LED
Off
Solid
Green
LED
Off
LED
Off
LED
Off
Solid
Green
LED
Off
LED
Off
Operation Standing Function (Only applies to VS Seat)
