Pfaff 1474 E1

Adjustment
13.05.03 Knife motion
Requirement
With the edge trimmer swung in and the needle in the needle hole, half of the motion of
the knife 1 must take place in front of the needle, and half behind it, when the motor shaft
is turned by hand.
● Turn the machine off and swing in the edge trimmer.
● Move the knife 1 (screw 2) in accordance with the requirement.
Fig. 13 - 26
1
2
1
½
½
13 - 31
