Pfaff 1474 E1

Adjustment
13.04.10 Needle setting in transverse direction to sewing ( 1474E1 )
Requirement
The needles must penetrate the center of their respective needle holes as viewed in
transverse direction of sewing.
● Move feed wheel post 1 ( screws 2 to both sides of the post ) according to the
requirement.
Fig. 13 - 09
2
2
1
13 - 14
