Pfaff 1474 E1

Adjustment
13.06 Adjusting the edge trimmer -725/04 for the 1474E1
13.06.01 Replacing the knife
● Turn the machine off.
● Loosen screw 1 and remove knife 2.
● Insert a new knife 2 and slide it flush against the needle plate insert.
● Tighten screw 1.
Check chapter 13.06.05 Knife position.
Fig. 13 - 28
2
1
13 - 33
