Pfaff 1474 E1

Adjustment
13.04.11 Bobbin case opener height
Requirement
The top edges of the bobbin case opener 1 and the bobbin case base 3 must be at the
same height.
Fig. 13 - 10
● Move the bobbin case base 1 ( screws 2 ) in accordance with the requirement.
Carry out the same adjustment on the right post if using the 1474E1 model.
2
1
1
3
13 - 15
