Pfaff 1474 E1

Adjustment
13.05.04 Knife position
Requirement
With the edge trimmer swung in, the knife must lightly touch the needle plate insert.
Make sure there is no whistling sound produced during the cutting process.
● Turn screw 1 (screw 2) according to the requirement.
● Carry out a test cut, and adjust anew if necessary.
Fig. 13 - 27
1
2
13 - 32
