Pfaff 1474 E1

Adjustment
13.04.05 Positioning the needle in the direction of sewing ( 1474E1 )
Requirement
The needles must penetrate the middle of the needle holes as viewed in the direction of
sewing.
● Move the needle bar frame 1 ( screws 2 and 3 as well as nut 4 ) in accordance with the
requirement.
Screws 3 are accessible through the holes on the back of the housing.
Fig. 13 - 04
2
4
1
3
3
13 - 7
