Pfaff 1474 E1

Adjustment
13.04.09 Needle setting in transverse direction to sewing ( 1471E1 )
Requirement
At maximum stitch length the needle must be positioned in the center of the needle hole
when penetrating and retracting from the needle plate.
Fig. 13 - 08
2
2
1
● Turn the machine on.
● Set stitch at maximum length and sew four or five stitches ( without trimming ).
● Turn the machine off.
● Turn screws 1 ( screws 2 to both sides of the post ) according to the requirement.
13 - 13
