Pfaff 1474 E1

7 - 2
Controls
7.03 Pedal
0 = Machine stop
1 = Sew
2 = Raise roller-presser
3 = Trim thread and raise roller-
presser
Other pedal functions can also
be programmed (see chapter
10 Sewing).
Fig. 7 - 03
0
1
2
3
7.04 Knee switch
● By activating the knee switch 1 the end
of the seam section can be signalized
during programmed sewing.
The function of the knee
switch 1 must be switched on
using the control panel (see
chapter 11 Programming).
Fig. 7 - 04
1
