Pfaff 1474 E1

Controls
7 - 3
7.05 Knee lever
● The roller-presser is raised by pressing
the knee lever 1 in the direction of the
arrow.
1
Fig. 7 - 05
7.06 Lever for lifting the roller presser
● The roller-presser is raised by turning
lever 1.
1474E1 is shown in Fig. 7 - 06
Fig. 7 - 06
1
