Philips HeartStart MRx - Connecting the NBP Interconnect Tubing

Connecting the NBP Interconnect Tubing 3 Setting Up
37
Connecting the NBP Interconnect Tubing
To connect the NBP Interconnect Tubing:
1 Insert the NBP Interconnect Tubing into the red NBP port as shown in Figure 20.
2 Attach the NBP Interconnect Tubing fitting to the NBP cuff.
Figure 20 Connecting NBP Interconnect Tubing / NBP Cuff
