4 ECG and Arrhythmia Monitoring Displaying an Annotated ECG
60
Displaying an Annotated ECG
You may choose to display an annotated ECG with arrhythmia beat labels in Wave Sector 2. The same
ECG source appearing in the Wave Sector 1 is displayed with a six second delay along with white
arrhythmia beat labels. See Table 8 below for additional information on beat classification.
Table 8 Arrhythmia Beat Labels
To display an annotated ECG:
1 Press the Menu Select button.
2 Using the Navigation buttons, select Displayed Waves and press the Menu Select button.
3 Select Wave 2 and press the Menu Select button.
4 Select Annotated ECG and press the Menu Select button.
Label Description Displayed Location
NNormal Above QRS
VVentricular Ectopic Above QRS
P Paced Above QRS
' Pacer spike Above the waveform where the pacer spike is
detected. (If the patient is both atrially and
ventricularly paced, the display will show two '
marks above the waveform aligned with the
atrial and ventricular pacing.)
L Learning Patient’s ECG Above QRS
A Artifact (noisy episode) Above the waveform where the noise is
detected.
? Insufficient information to classify beats Above QRS
I Inoperative condition (e.g. LEAD OFF) Above the waveform at start of INOP, every
second of INOP, and at end of INOP.
M Pause, Missed Beat, No QRS Above the waveform where the condition is
detected.
