Pacing View 7 Noninvasive Pacing
85
Pacing View
Pacing View appears when the Therapy Knob is set to the Pacer position. Figure 51 shows information
displayed in Pacing View.
Figure 51
Pacing View includes a status block which appears in Wave Sector 4 of the display. The first line of the
status block communicates whether pacing is active or paused. If pacing is powered by batteries, this is
indicated here as well, if configured. The second line of the status block identifies the Pacer Mode
(demand or fixed), pacing rate (ppm), and pacing output (mA).
Soft keys are available for setting pacing status ([Start Pacing], [Pause Pacing],
[Resume Pacing]) and adjusting [Pacer Rate], [Pacer Output].
Mark Event
