5 Semi-Automated External Defibrillation AED View
64
AED View
Once the Therapy Knob is moved to AED, AED View is displayed.
Figure 39 AED View Display
Wave Sectors 1 and 2 are combined so that a large ECG may be shown. The Event Timer is also large
for easier viewing. A Shock Counter is displayed just below the ECG and shows the total number of
shocks delivered to the patient in AED and Manual Defib Mode. Also below the ECG is a prominent
text message window which accompanies the voice prompts annunciated in AED Mode.
NOTE Only the ECG acquired through multifunction electrode pads is displayed in AED Mode.
Alarms Off
Mark Event
10 Feb 2006 11:20
P
a
d
s
HR
154 02:42
Analyzing
Do Not Touch Patient
P
a
u
se
f
o
r
C
P
R
M
E
NU
S
ho
cks
:
0
