Configuration and diagnostics in web-based management
107065_en_01 PHOENIX CONTACT 37
Transfer via TFTP: select “TFTP” as the transfer method.
TFTP server IP address: here you should enter the IP address via which the TFTP server
can be reached.
Remote filename: here you should enter the name of the file to be uploaded or downloaded.
Figure 5-14 “Advanced Configuration” pop-up
Pop-up: Security Context
Create new context: clicking on the “Generate” button creates all the necessary keys and
certificates for operation with HTTPS and SSH.
Current state: displays the status of the current availability of the security context.
Root CA: clicking on the “cacert.cer” link loads the Root CA certificate for the installation in
the browser.
Advanced Configuration: clicking on the “File transfer” link opens the “Advanced Configura-
tion” pop-up (see “Pop-up: Advanced Configuration” on page 35).
Figure 5-15 “Security Context” pop-up
