FL SWITCH 2000
80
PHOENIX CONTACT 107065_en_01
Current consumption at US for 12 V DC, maximum (without digital output) 1.4 A (FL SWITCH 2204-2TC-2SFX)
1.4 A (FL SWITCH 2206-2SFX)
Current consumption at US for 24 V DC, maximum (without digital output) 170 mA (FL SWITCH 2205)
190 mA (FL SWITCH 2208)
220 mA (FL SWITCH 2207-FX)
220 mA (FL SWITCH 2207-FX SM)
260 mA (FL SWITCH 2206-2FX)
260 mA (FL SWITCH 2206-2FX SM)
260 mA (FL SWITCH 2206-2FX ST)
260 mA (FL SWITCH 2206-2FX SM ST)
250 mA (FL SWITCH 2204-2TC-2SFX)
230 mA (FL SWITCH 2206-2SFX)
Test voltage 170 V DC for one minute
Supply voltage (US1/US2 redundant) (Fortsetzung)
Interfaces
Number of Ethernet ports 5 / 8
Digital alarm output
Voltage 12 - 58 V DC
Current carrying capacity 100 mA, typical/0.7 A, maximum (1 minute)
Ethernet interfaces
Properties of the RJ45 ports
Number Up to 8 with auto crossing and auto negotiation
Connection format 8-pos. RJ45 socket on the switch
Connection medium Twisted pair cable
Cable impedance 100 ohms
Transmission speed 10/100 Mbps
Maximum network segment expansion 100 m
Properties of the fiberglass ports
Number Up to 2
Connection format SC/ST/SFX format (depending on the device used)
Connection medium Fiberglass
Connecting plug SC/ST/LC format (depending on the device used)
Transmission speed 100 Mbps
Maximum network segment expansion Depends on the SFP module/fiber type used
Fiber type Depends on the SFP module/fiber type used
Laser protection class 1
Wavelength 850/1310 nm (depending on the device/SFP module used)
Properties of the combo ports
Number Up to 2
Transmission speed 100 Mbps
Wavelength Depends on the SFP module used
Maximum transmission length Depends on the SFP module used
