Technical data and ordering data
107065_en_01 PHOENIX CONTACT 75
11 Technical data and ordering data
11.1 Technical data for devices in the 2000 version
General data
Function Ethernet/Fast Ethernet Switch; conforms to standard IEEE 802.3/802.3u
Switch principle Store and forward
Address table 8192 MAC addresses
SNMP Version 2c, Version 3
Transmission capacity per port
64-byte packet size, half duplex
At 10 Mbps: 14880 pps (packets per second)
At 100 Mbps: 148800 pps
Supported MIBs MIB II and private SNMP objects from Phoenix Contact
Housing dimensions (width x height x depth) in mm 45 x 130 x 115 (depth from top edge of DIN rail)
Permissible operating temperature 0°C to 60°C
Permissible storage temperature -40°C to +85°C
Degree of protection IP20 (not assessed in compliance with UL, assessed by PTL), IEC 60529
Protection class Class 3 VDE 0106; IEC 60536, for inside use only
Humidity
Operation 10% to 95%, non-condensing
Storage 10% to 95%, non-condensing
Air pressure
Operation 86 kPa to 108 kPa, 1500 m above sea level
Storage 66 kPa to 108 kPa, 3500 m above sea level
Ambient compatibility Free from substances that would hinder coating with paint or varnish accord-
ing to VW specification
Mounting position Perpendicular to a standard DIN rail
Connection to protective earth ground Snapped onto a grounded DIN rail
Pollution degree 2
Overvoltage category None
Weight Up to 220 g, typical
Supply voltage (US)
Connection Via COMBICON; maximum conductor cross section = 1.5 mm
2
, use copper
wires that are suitable for 75°C or equivalent
Nominal value 24 V DC
Permissible voltage range 18 V DC to 32 V DC
Permissible ripple (within the permissible voltage range) 3.6 V
PP
Current consumption at US for 18 V DC, maximum 300 mA (FL SWITCH 2005)
350 mA (FL SWITCH 2008)
Current consumption at US for 24 V DC, maximum 165 mA (FL SWITCH 2005)
180 mA (FL SWITCH 2008)
Test voltage 170 V DC for one minute
Interfaces
Number of Ethernet ports 5 / 8
