Technical data and ordering data
107065_en_01 PHOENIX CONTACT 79
Permissible operating temperature -40°C to 70°C
Permissible storage temperature -40°C to +85°C
Degree of protection IP20 (not assessed in compliance with UL, assessed by PTL), IEC 60529
Protection class Class 3 VDE 0106; IEC 60536, for inside use only
Humidity
Operation 10% to 95%, non-condensing
Storage 10% to 95%, non-condensing
Air pressure
Operation 68 kPa to 108 kPa, 3000 m above sea level
Storage 66 kPa to 108 kPa, 3500 m above sea level
Ambient compatibility Free from substances that would hinder coating with paint or varnish accord-
ing to VW specification
Mounting position Perpendicular to a standard DIN rail
Connection to protective earth ground Snapped onto a grounded DIN rail
Pollution degree 2
Overvoltage category None
Weight Up to 260 g, typical
General data
Supply voltage (US1/US2 redundant)
Connection Via COMBICON; maximum conductor cross section = 1.5 mm
2
, use copper
wires that are suitable for 75°C or equivalent
Nominal value 24 V DC
Permissible ripple (within the permissible voltage range) 3.6 V
PP
Permissible voltage range 9 V DC to 57 V DC for the following devices
FL SWITCH 2205
FL SWITCH 2208
FL SWITCH 2207-FX
FL SWITCH 2207-FX SM
FL SWITCH 2206-2FX
FL SWITCH 2206-2FX SM
FL SWITCH 2206-2FX ST
FL SWITCH 2206-2FX SM ST
Permissible voltage range 12 V DC to 57 V DC for the following devices
FL SWITCH 2204-2TC-2SFX
FL SWITCH 2206-2SFX
Current consumption at US for 9 V DC, maximum (without digital output) 1.2 A (FL SWITCH 2205)
1.3 A (FL SWITCH 2208)
1.4 A (FL SWITCH 2207-FX)
1.4 A (FL SWITCH 2207-FX SM)
1.5 A (FL SWITCH 2206-2FX)
1.5 A (FL SWITCH 2206-2FX SM)
1.5 A (FL SWITCH 2206-2FX ST)
1.5 A (FL SWITCH 2206-2FX SM ST)
