Technical data and ordering data
107065_en_01 PHOENIX CONTACT 77
SNMP Version 2c, Version 3
Transmission capacity per port
64-byte packet size, half duplex
At 10 Mbps: 14880 pps (packets per second)
At 100 Mbps: 148800 pps
At 1000 Mbps: 1488100 pps
Supported MIBs MIB II and private SNMP objects from Phoenix Contact
Housing dimensions (width x height x depth) in mm 45 x 130 x 115 (depth from top edge of DIN rail)
Permissible operating temperature 0°C to 60°C
Permissible storage temperature -40°C to +85°C
Degree of protection IP20 (not assessed in compliance with UL, assessed by PTL), IEC 60529
Protection class Class 3 VDE 0106; IEC 60536, for inside use only
Humidity
Operation 10% to 95%, non-condensing
Storage 10% to 95%, non-condensing
Air pressure
Operation 86 kPa to 108 kPa, 1500 m above sea level
Storage 66 kPa to 108 kPa, 3500 m above sea level
Ambient compatibility Free from substances that would hinder coating with paint or varnish accord-
ing to VW specification
Mounting position Perpendicular to a standard DIN rail
Connection to protective earth ground Snapped onto a grounded DIN rail
Pollution degree 2
Overvoltage category None
Weight Up to 240 g, typical
General data
Supply voltage (US)
Connection Via COMBICON; maximum conductor cross section = 1.5 mm2, use copper
wires that are suitable for 75°C or equivalent
Nominal value 24 V DC
Permissible voltage range 18 V DC to 32 V DC
Permissible ripple (within the permissible voltage range) 3.6 V
PP
Current consumption at US for 18 V DC, maximum 350 mA (FL SWITCH 2105)
400 mA (FL SWITCH 2108)
Current consumption at US for 24 V DC, maximum 225 mA (FL SWITCH 2105)
275 mA (FL SWITCH 2108)
Test voltage 170 V DC for one minute
Interfaces
Number of Ethernet ports 5 / 8
Ethernet interfaces
Properties of the RJ45 ports
Number Up to 8 with auto crossing and auto negotiation
Connection format 8-pos. RJ45 socket on the switch
Connection medium Twisted pair cable
