Title Service Manual, LPCR2 Page
Service Product Drawing
3323299
B
Released State Date 11/14/2017
7000545 Revision A
Safety - Technical Description
The following information is provided to comply with Clause 7.9.3 in IEC 60601-1 (3
rd
Edition) for information that is
“essential for safe operation, transport and storage, and measures or conditions necessary for installing the
ME
EQUIPMENT
, and preparing it for use”. This information includes:
a) Explanation of information on the serial label
b) Explanation of symbols used on the device including Cl. 6 (IEC 60601-1) applicable classifications (Type BF,
IP55) and an explanation of safety signs and other symbols.
c) For reference, the general danger and warning statements from the LIFEPAK CR2 Defibrillator Operating
Instructions, 3321515.
d) A brief description of the LIFEPAK CR2 Defibrillator and its functions, and the device’s significant physical and
performance characteristics.
e) Information concerning circuit diagrams, component lists available for authorized service representatives
Serial Label Information
Symbols
The symbols in the following table may be found on the defibrillator, its accessories, or packaging.
ON/OFF button
LANGUAGE button
CHILD MODE button
SHOCK button (on semi-automatic devices)
SHOCK indicator (on fully automatic devices)
To Next Page
