Title Service Manual, LPCR2 Page
Service Product Drawing
3323299
B
Released State Date 11/14/2017
7000545 Revision A
Overview:
1. One time use, 4 years shelf life
2. Pads function: Pacing/ECG/Defibrillation
3. Analyzes heart rhythm and delivers a shock
4. Pads can be used on both adults and children
5. If patient care is transferred to emergency medical personnel, electrode pads can be transferred to another
LIFEPAK defibrillator (except LIFEPAK 500).
Connectivity Module
The LIFEPAK CR2 defibrillator has a built-in connectivity module that can connect to LIFELINK or LIFENET System
using Wi-Fi, or Cellular, or USB connection.
• USB port on the device is a standard option
• Wi-Fi configuration is optional, it has a built-in modem
• Cellular configuration is optional, it has a built-in active SIM card plus Wi-Fi modem
To determine whether the CR2 has Wi-Fi or cellular capability, check the serial number label (located in the battery
compartment).
NOTE: All LIFEPAK CR2 devices with cellular capability also have Wi-Fi capability.
