Title Service Manual, LPCR2 Page
Service Product Drawing
3323299
B
Released State Date 11/14/2017
7000545 Revision A
Functional Descriptions
The LIFEPAK CR2 defibrillator is a portable, battery-powered therapeutic device. It consists of the following
components:
• One PCB – the printed circuit board controls defibrillator functions, including ECG signal processing, mode
control, rhythm and motion analysis, energy storage capacitor charging, impedance sensing, voice prompting,
generation of biphasic defibrillation waveform, and patient event recording.
• Protective Lid – protects user interface and electrode tray during standby; controls defibrillator On/Off when lid
is opened or closed.
• Wi-Fi Module – handles wireless connection to LIFENET System.
• Cellular Module – handles cellular connection to LIFENET System.
• USB connector – provides connection between defibrillator and computer to handle communication from
defibrillator to the LIFENET System.
• Tray and Electrodes – electrodes are connected to the tray and the tray is plugged into the tray connector in
the defibrillator.
