NOTE:
• Self-test pass: 3 audible tones sound and the green Readiness indicator is flashing every 6 seconds through a
small hole located on top of the lid, the self-test has been completed and passed.
• Self-test fail: If there are no audible tones or the Readiness indicator is not flashing, the self-test has failed.
Refer to Troubleshooting for possible solutions.
Device Daily, Weekly, and Monthly Tests
Self-test to run based on Temperature ranges (as marked by X)
Freq.
Temperature Affect for …
[using T for temperature in
degrees Celsius]
Operating
0<=T<=50
Out of Range
-45<=T<0 or 50<T<=100
Broken
Sensor
T<-45 or
T>100
Daily
ELECTRODES EXPIRATION test
X
X
X
Daily
BATTERY EXPIRATION test
X
X
X
Daily
HIGH LIMIT OCV (open-circuit
voltage) test
X
Daily
BATTERY OCV (open-circuit
voltage) test
- OCV Voltage Drop test
- OCV Voltage Level test
X
Daily
TEMPERATURE test
- Sensor Test
- Operating Test
X
X
X
Weekly
RAM CONNECTION test
X
X (unless triggered
through Monthly test)
X
Weekly
INTERPROCESSOR
COMMUNICATION test
X
X (unless triggered
through Monthly test)
X
Monthly
BATTERY LOAD test
- Voltage Level test
X
Monthly
PREAMP ECG test
- pacer pulse detection test
- ECG Single-Step test
X
X
Monthly
PREAMP IMPEDANCE test
X
X
Monthly
ISOLATION RELAY test
- Relay Close test
- Relay Open test
X
X
Monthly
H-BRIDGE test
- Phase 1 (NW to SE) Conduction
test
- Phase 2 (NE to SW) Conduction
test
X
X
Monthly
CHARGE RATE test
X
X
Monthly
VCAP MEASUREMENT test
X
X
Monthly
SPEAKER test
X
X
