Title Service Manual, LPCR2 Page
Service Product Drawing
3323299
B
Released State Date 11/14/2017
7000545 Revision A
Biphasic waveform at 200 joules, nominal
PATIENT
IMPEDANCE (
)
I1 (A) I2 (A) I3 (A) I4 (A)
T1
(MS)
T2
(MS)
25 58.1 21.0 20.9 10.6 5.0 3.3
50 30.0 14.8 14.8 9.2 6.9 4.7
75 20.7 11.8 11.8 8.1 8.3 5.5
100 16.0 9.9 9.9 7.3 9.3 6.2
125 13.2 8.7 8.7 6.6 10.1 6.7
150 11.3 7.8 7.8 6.1 10.8 7.2
175 9.9 7.1 7.1 5.7 11.4 7.6
Biphasic waveform at 90 joules, nominal
PATIENT
IMPEDANCE (
)
I1 (A) I2 (A) I3 (A) I4 (A)
T1
(MS)
T2
(MS)
25 33.1 12.0 11.9 6.1 5.0 3.3
50 20.1 9.9 9.9 6.2 6.9 4.6
75 13.9 7.9 7.9 5.4 8.3 5.5
100 10.7 6.7 6.7 4.9 9.3 6.2
125 8.8 5.8 5.8 4.4 10.1 6.7
150 7.6 5.2 5.2 4.1 10.8 7.2
175 6.7 4.8 4.8 3.8 11.4 7.6
Shock Advisory
System
ECG analysis system used by this device. The Shock Advisory
System determines whether a shock is appropriate.
Note: The fully automatic device cannot cancel delivery of a shock
after the Shock Advisory System determines a shock is advised. The
semi-automatic device cancels the shock if the
SHOCK button is not
pressed within 15 seconds.
cprINSIGHT
Analysis
Technology
Additional ECG analysis system that is designed to analyze the ECG
rhythm while CPR is being performed. The cprINSIGHT Analysis
Technology can be set to be
ON or OFF. When this feature is turned
on, the voice prompts change so the user is instructed to continue
CPR during analysis.
Device Capacity With new battery:
Provides 166 200-joule shocks (with 1 minute of CPR between
shocks), 103 360-joule shocks (with 1 minute of CPR between
shocks), or 900 minutes of operating time.
When device has just reached a low battery state (Readiness
indicator has stopped flashing):
Provides 39 200-joule shocks (with 1 minute of CPR between
shocks), 24 360-joule shocks (with 1 minute of CPR between
shocks), or 210 minutes of operating time.
