Title Service Manual, LPCR2 Page
Service Product Drawing
3323299
B
Released State Date 11/14/2017
7000545 Revision A
Operating
Temperature
0° to 50°C (32° to 122°F)
Long-term Storage
Temperature
0° to 25°C (32° to 77°F)
Short-term Storage
Temperature
-30° to 60°C (-22° to 140°F) for up to 1 week
Relative Humidity 5 to 95% non-condensing
QUIK-STEP
Electrodes
Pads Pacing/ECG/defibrillation electrodes
Packaging Pre-connected tray with rapid-release cover
Shelf Life 4 years
1
Electrode Shape Oval-rectangular
Electrode Size 13.34 x 8.89 cm (5.25 x 3.50 in)
Conductive Gel
Contact Area
82 cm
2
(32 in
2
)
Maximum Adhesion
Time
4 hours
Maximum ECG
Monitoring Time
4 hours
Maximum Number
of Defibrillation
Shocks
20 at 360 joules
Maximum Pacing
Duration
1 hour
Operating
0° to 50°C (32° to 122°F)
Long-Term Storage
Temperature
15° to 35°C (59° to 95°F)
Short-Term Storage
Temperature
-30° to 60°C (-22° to 140°F) for up to 1 week
Altitude -382 to 4572 meters (-1253 to 15,000 feet) above sea level
1
Based on historical storage temperature data, the 4-year shelf life assumes a storage temperature of 25°C (77°F). Average storage temperatures
above 25°C (77°F) may decrease shelf life.
