7000545 Revision A
Connection In Progress
After completion of "Wi-Fi Connection Initiated",
and attempt to establish a Wi-Fi connection to
LIFENET. During connection attempt, device
beeps every 5 seconds.
Unable to Establish Wi-Fi
Network
If Wi-Fi connection cannot be established from
CR2 to Wi-Fi access point. See “Unable to
establish Wi-Fi network connection” for detail.
Connection Failed
Connection between Wi-Fi access point to
LIFENET timeout. This voice prompt means the
CR2 can reach the Wi-Fi access point, but it
cannot connect to LIFELINK or LIFENET System.
See “Connection Failed” for detail.
LIFENET Connection Error
An error has occurred while attempting to connect
to LIFELINK or LIFENET System. Contact
SmartDesk for support.
Connection Established
Once LIFENET connection has been established.
First HTTP response is an OK. Start LIFENET
Check-In after the completion of "Connection
Established"
This May Take Several
Minutes
After the completion of "Connection Established"
and before performing LIFENET Check-In. During
LIFENET Check-In, device will beep every 5
seconds.
Update In Progress
When software update is initiated with LIFNET
Rebooting
Once software update is complete and ready for
reboot. Software shall reboot after this prompt.
When reboot is done, "Wi-Fi connection Initiated"
prompt plays again.
Communication Complete
After LIFENET Check-In completes.
Connection Lost
If current LIFENET Check-In session aborts after a
successful LIFENET connection has been
established. Try again, if the same voice prompt
occurs, contact SmartDesk for support.
Powering Off
After completion of Wi-Fi Troubleshooting, if no
Cell configured on the device.(If cell is configured,
this prompt is heard after cellular connection. See
cellular troubleshooting.)
Cellular
Troubleshooting:
Voice Prompt
What/When this prompt can be heard
Mobile Connection Initiated
After Wi-Fi "Communication Complete" or "Wi-Fi
not Configured" prompt and if Cell configured on
the device. The software will perform Cellular
Troubleshooting when entering Data Mode.
Connection In Progress
After completion of "Mobile Connection Initiated",
and attempt to establish a cellular network
connection to LIFENET. During connection
attempt, device beeps every 5 seconds.
Unable to Establish Mobile
Network
If a cellular network connection cannot be
established. Check cellular signal from a smart
phone and try again.
Connection Failed
If transmission timeout occurs before a successful
connection to LIFENET. Check cellular signal from
a smart phone and try again.
