4.13
Section 4
Pinnacle PcX OPeratiOn
Pinnacle Operators Manual
Pickering Laboratories Inc.
Next, click on the Column Tab, then click once in the box under Time. The cursor should now be flashing
here. Type in your desired Times and temperatures below. Use the Add button to add lines to the table. Use
the data from the table below as a guide. Time is the elapsed time in minutes. Temperature is in °C and is the
desired temperature of the column at the time specified.
Time, min Temp, °C
5.0 45
9.5 48
25 56
50 75
Now Click Save. This has saved the conditions you have created in the method “Tutorial”.
Click Close to close the Edit Method Window.
Next, we will go through the Create Sequence Tutorial.
CREATE A SEQUENCE
As with the above method, this example sequence is not designed to be used for analysis. It will guide you
through the steps and you may use your own method for the Sequence Table.
From the main Status Window, go to Sequence, then select Edit/Delete.
This will open the Sequence Edit Screen. Here you will set the method names, and the number of injections for
each method.
Click Create Sequence.
Type a Name for your Sequence. For this example, type “Tutorial 1” and click OK.
The Pinnacle PCX software has now added the Sequence “Tutorial 1” to the list of available sequences. Highlight
this sequence if it is not already done so.
Under Method Name, there is a drop down menu. Choose the Method “Tutorial”.
