Pioneer MEP-7000 Service Manual

162
MEP-7000
1
2 3 4
A
B
C
D
E
F
1
2 3 4
10.10 SLMB1 ASSY
FF
F
SLMB1 ASSY (DWS1401)
CN101
E
To Loading Motor
To Stepping Motor
Slot in Mecha SW
DGND
DSG1017-A
S4401
12
DSG1017-A
S4400
12
CN4402
KM200NA3L
1
2
3
CN4401
KM200NA9LE
1
2
3
4
5
6
7
8
9
CN4400
SLW4R-1C7
1
2
3
4
ST1-
ST1+
ST2+
ST2-
LPS2
DGND
LPS1
ST1+
ST2+
ST2-
ST1-
LO-
LO+
LO+
LO-
NC

Pioneer MEP-7000 Specifications

General

Frequency range	4 - 20000 Hz
Channels quantity	- channels
Digital sound processing	- bit
Total Harmonic Distortion (THD)	0.006 %
Dimensions (WxDxH)	483 x 325 x 91 mm
Power consumption (typical)	33 W

Weight and Dimensions

Weight	6100 g
