Pioneer MEP-7000 Service Manual

138
MEP-7000
1
2 3 4
A
B
C
D
E
F
1
2 3 4
9.3 FRONT PANEL SECTION
CONTACT SIDE
NON-CONTACT
SIDE
KUCXJ only
B
G
C
SMAIN
CN400
SMAIN
CN350
Note:
When tightening screws 20 ,
tighten Screw A first then Screw B.
A
B
Note:
Note that the type of
the screws 20 is M, but not B Tight.
Note:
Attach the Panel 4 to the
Panel Stays 11 with the screws.

Pioneer MEP-7000 Specifications

General

Frequency range	4 - 20000 Hz
Channels quantity	- channels
Digital sound processing	- bit
Total Harmonic Distortion (THD)	0.006 %
Dimensions (WxDxH)	483 x 325 x 91 mm
Power consumption (typical)	33 W

Weight and Dimensions

Weight	6100 g
