Page #30 background imageLoading...
Page #30 background image
30
MEP-7000
1
2 3 4
A
B
C
D
E
F
1
2 3 4
3.2 PCB LOCATIONS
DRIVE UNIT
A
SMAIN ASSY
J
POWER SUPPLY UNIT
HE
SRV2 ASSY SLOT-IN MECHANISM ASSYSLOT-IN MECHANISM ASSY
G
USBB ASSY
C
FSWB ASSY
I
SLMB2 ASSY
B
EJTB ASSY
F
SLMB1 ASSY
SRV1 ASSY
D
SJACK ASSY
K
ACIN ASSY
