Pioneer MEP-7000 Service Manual

31
MEP-7000
5
6 7 8
5
6 7 8
A
B
C
D
E
F
DRIVE UNIT
1..SMAIN ASSY DWX2706
NSP 1..SERVO ASSY DWM2297
2..SRV1 ASSY DWX2711
2..SRV2 ASSY DWX2712
NSP 1..SSUB ASSY (KUCXJ) DWM2332
NSP 1..SSUB ASSY DWM2333
(WYXJ5, TLFXJ, WAXJ5)
2..ACIN ASSY (KUCXJ) DWR1438
2..ACIN ASSY DWR1439
(WYXJ5, TLFXJ, WAXJ5)
2..FSWB ASSY DWS1400
2..SLMB1 ASSY DWS1401
2..SLMB2 ASSY DWS1402
2..EJTB ASSY DWS1403
2..SJACK ASSY DWX2896
2..USBB ASSY DWX2713
> 1..POWER SUPPLY UNIT DWR1440
NSP 1..
SLOT-IN MECHANISM ASSY (2 pair) DXA2123
CONTROL UNIT
1..NMAIN ASSY DWX2705
NSP 1..OELB ASSY (2 pair) DWX2714
NSP 1..SIDE ASSY (2 pair) DWM2300
2..DISP ASSY DWX2707
2..JOGR ASSY DWX2709
2..JOGT ASSY DWX2750
NSP 1..NSUB ASSY DWM2298
2..RENC ASSY DWS1399
2..NJACK ASSY DWX2708
2..DJACK ASSY DWX2788
CONTROL UNIT (CU-V170)
M
NJACK ASSY
O
DJACK ASSY
S
OELB ASSY
P
DISP ASSY
P
DISP ASSY
Q
JOGT ASSY
Q
JOGT ASSY
N
RENC ASSY
L
NMAIN ASSY
R
JOGR ASSY
R
JOGR ASSY
S
OELB ASSY
Mark No. Description Part No. Mark No. Description Part No.
LIST OF ASSEMBLIES
NOTES:
-
Parts marked by “NSP” are generally unavailable because they are not in our Master Spare Parts List.
-
The > mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.

Pioneer MEP-7000 Specifications

General

Frequency range	4 - 20000 Hz
Channels quantity	- channels
Digital sound processing	- bit
Total Harmonic Distortion (THD)	0.006 %
Dimensions (WxDxH)	483 x 325 x 91 mm
Power consumption (typical)	33 W

Weight and Dimensions

Weight	6100 g
