Pioneer MEP-7000 Service Manual

144
MEP-7000
1
2 3 4
A
B
C
D
E
F
1
2 3 4
9.6 CONTROL PANEL SECTION
NMAIN
CN602
NMAIN
CN600
A
A
B
B
A
B
CONTACT SIDE
NON-CONTACT
SIDE
R
Q
P
P
DSP
CN2603
S
Daifree
*1
*1
*2
*2
GEM1036
(ZLX-ME413A)
Lubricating Oil
GYA1001
(ZLB-PN397B)
Lubricating Oil
GYA1001
(ZLB-PN397B)
Note: Do not spread the
Lubricating oil on
No.11 and 12.
Note :
For details on how to apply grease,
see “1.6 REASSEMBLING THE CONTROL UNIT” in this manual.
Note :
Be sure to place the convex surface of 12 toward 11 .
See “1.6 REASSEMBLING THE CONTROL UNIT” in this manual.

Pioneer MEP-7000 Specifications

General

Frequency range	4 - 20000 Hz
Channels quantity	- channels
Digital sound processing	- bit
Total Harmonic Distortion (THD)	0.006 %
Dimensions (WxDxH)	483 x 325 x 91 mm
Power consumption (typical)	33 W

Weight and Dimensions

Weight	6100 g
