Pioneer MEP-7000 Service Manual

143
MEP-7000
5
6 7 8
5
6 7 8
A
B
C
D
E
F
(1) EXTERIOR SECTION PARTS LIST
(2) CONTRAST TABLE
MEP-7000/KUCXJ, WYXJ5, TLFXJ and WAXJ5 are constructed the same except for the following:
Mark No. Description Part No.
1 NMAIN Assy DWX2705
2 RENC Assy DWS1399
3 DJACK Assy DWX2788
4 NJACK Assy DWX2708
5 LCD Module DWX2754
6 13P FFC DDD1404
7 18P FFC DDD1405
8 24P FFC DDD1406
9 TFT Cushion DEC3003
10 Protection Tape DEC3066
11 TFT Holder DNH2791
12 Aluminum Tape DEF1019
13 EMC Sheet 45x45 DEC3095
14 FFC Guard 6x16 DEC3065
15 TFT Shield DNH2792
16 Guard Cushion DEC3106
17 Center Panel DNK5244
18 Eject Guard DNK4920
19 Jog Ring DNK4926
20 Slide Knob DNK4982
21 Dial Knob DNK4924
22 Control Panel DNB1150
23 Dial Lens DNK4925
24 Flange Nut M7 DBN1011
25 Earth Plate F BLACK DBK1323
26 Slide VR Packing DED1157
27 OEL Panel DAH2513
28 Earth Plate SC DBK1313
29 Shade Sheet DEC3064
30 Load Knob DNK4923
31 Mode Knob DNK4913
32 Mode Lens DNK5036
33 EMC Sheet 20x55 DEC3096
34 Jack Holder DNH2795
35 Locking Card Spacer XEC3051
36 Upper Bracket DNH2809
37 Rear Panel See Contrast table (2)
38 Leg Assy DXA2124
39 Function Knob DNK4922
40 LR Knob DNK4911
41 Screw BPZ20P080FTB
42 Screw DBA1340
43 Screw BPZ30P080FTC
44 Screw AMZ20P040FTC
45 Screw ABA7127
46 Screw BBZ30P080FTB
47 KNOB Cushion DEC3131
Mark
No. Description Part No.
Mark No. Symbol and Description MEP-7000/KUCXJ MEP-7000/WYXJ5 MEP-7000/TLFXJ
MEP-7000/WAXJ5
37 Rear Panel DNC1825 DNC1884 DNC1885
DNC1855

Pioneer MEP-7000 Specifications

General

Frequency range	4 - 20000 Hz
Channels quantity	- channels
Digital sound processing	- bit
Total Harmonic Distortion (THD)	0.006 %
Dimensions (WxDxH)	483 x 325 x 91 mm
Power consumption (typical)	33 W

Weight and Dimensions

Weight	6100 g
