1.5 CABLE DRESSING OF THE DRIVE UNIT
How you dress the cables connected to the SJACK Assy greatly affects the sound quality from the unit. During
disassembly and reassembly of the drive unit, be careful of cable dressing. At the end of reassembly, be sure to
check that the cable dressing is performed as shown below.
For performance improvement, cable dressing methods have been changed several times in the middle of mass
production of this product.
During cable dressing of this product, be careful of the following points:
CASE 1
[1] When cables are disconnected from the SJACK Assy
[2] When the SJACK Assy is replaced
It is essential that the cables be dressed as
they originally were.
When the DWX2710 is replaced with the DWX2896 :
See Fig .
Parts to be added during servicing :
FFC guard (DEC2586) &
Shield Sheet (DEC3151) &
Locking Mini Clamp (DEC2439)
Parts to be added during servicing :
FFC guard (DEC2586) &
Shield Sheet (DEC3151) &
Locking Mini Clamp (DEC2439)
Parts to be added during servicing :
Locking Mini Clamp (DEC2439)
Parts to be added during servicing :
None
When the DWX2896 in the initial cable dressing state is replaced :
See Fig .
When cables are disconnected from the DWX2710 :
See Fig .
When cables in the initial dressing state are disconnected from
the DWX2896 :
See Fig .
When cables in the temporary dressing state are disconnected
from the DWX2896 :
See Fig .
When cables in the permanent dressing state are disconnected
from the DWX2896 :
See Fig .
CASE 2
CASE 3
CASE 4
CASE 5
CASE 6
When the DWX2896 in the temporary cable dressing state is
replaced :
See Fig .
CASE 7
When the DWX2896 in the permanent cable dressing state is
replaced :
See Fig .
CASE 8

Pioneer MEP-7000 Specifications

General

Frequency range	4 - 20000 Hz
Channels quantity	- channels
Digital sound processing	- bit
Total Harmonic Distortion (THD)	0.006 %
Dimensions (WxDxH)	483 x 325 x 91 mm
Power consumption (typical)	33 W

Weight and Dimensions

Weight	6100 g
