(1) EXTERIOR SECTION PARTS LIST
(2) CONTRAST TABLE
MEP-7000/KUCXJ, WYXJ5, TLFXJ and WAXJ5 are constructed the same except for the following:
Mark No. Description Part No.
1 ACIN Assy See Contrast table (2)
2 SJACK Assy DWX2710
> 3 POWER SUPPLY Unit DWR1440
4 SLMB1 Assy DWS1401
5 SLMB2 Assy DWS1402
6SRV1 Assy DWX2711
7SRV2 Assy DWX2712
8 SMAIN Assy DWX2706
9 Connector Assy 7P PF07PP-C15
10 Connector Assy 3P PF03PP-C17
11 Connector Assy 8P PF08PP-C27
12 Connector Assy 5P DKP3784
13 Connector Assy 15P DKP3783
14 40P FFC DDD1355
15 Connector Assy 5P PF05PP-C37
16 Connector Assy 9P DKP3782
17 24P FFC DDD1357
18 • • • • •
19 20P FFC DDD1402
20 Mecha Plate DNH2642
21 Earth lead Unit DDF1035
22 Binder ZCA-SKB90BK
23 Earth Spring DBH1398
24 Float Spring G5 DBH1494
25 Damper CNV6011
26 PCB Shield SLMB DEC3059
27 Rivet 3x4.5 RBM-003
28 Power Knob DNK4900
29 SW Bracket DNH2786
30 Cord Clamper RNH-184
31 Rear Stay DNH2785
32 Locking Mini Clamp DEC2439
33 EMC Sheet 20x55 DEC3096
34 Mecha Base DNK4906
35 PCB Stay Assy DXB1988
36 Laser Caution See Contrast table (2)
NSP 37 Chassis DNA1358
38 Gasket DEC3080
39 Insulator DEC2348
NSP 40 Spacer AEB7092
41 Bottom Plate DNH2784
42 Bonnet (BOX) DXX2592
43 Rear Panel See Contrast table (2)
44 Screw BBZ30P060FTB
45 Screw BBZ40P080FTB
46 Screw BPZ30P080FTC
47 Screw PBZ30P080FTB
48 Screw(M3x5) DBA1340
49 DM Screw(FTC) DBA1260
50 Screw CMZ30P080FTB
51 Screw AMZ30P040FTC
52 Float Cushion DEC3121
NSP 53 Label See Contrast table (2)
Mark
No. Description Part No.
Mark No. Symbol and Description MEP-7000/KUCXJ MEP-7000/WYXJ5 MEP-7000/TLFXJ
MEP-7000/WAXJ5
1 ACIN Assy DWR1438 DWR1439 DWR1439
DWR1439
36 Laser Caution VRW2257 VRW2257 VRW2159
DRW2372
43 Rear Panel DNC1823 DNC1851 DNC1908
DNC1853
NSP
53 Label DRW1975 Not used Not used
Not used
