Piper PA-28-161 Maintenance Manual

PIPER AIRCRAFT, INC.
PA-28-161, WARRIOR III
MAINTENANCE MANUAL
PAGE 2
Nov 30/06 5G2
91 - CONTENTS
CHAPTER 91 - CHARTS & WIRING DIAGRAMS
TABLE OF CONTENTS (continued)
SUBJECT SECTION PAGE GRID NO.
WIRING DIAGRAMS (SCHEMATICS) (continued)
Subject Grid No.
Primary Flight Display (PFD) 5J10
Radio Master Switch 5H9
Stall Warning 5H21, 5I11
Standby Alternator 5H17
Standby Attitude Indicator 5J12
Starter 5H14, 5I22, 5J19
Tachometer 5J15
Terminal Blocks 5H15
Turn and Bank Indicator 5J9
Subject Grid No.

Piper PA-28-161 Specifications

General

Manufacturer	Piper Aircraft
Model	PA-28-161 Warrior II
Engine	Lycoming O-320-D3G
Horsepower	160 hp
Seating Capacity	4
Wingspan	35 ft (10.7 m)
Length	24 ft 0 in
Maximum Speed	127 knots
Cruise Speed	122 knots
Maximum Takeoff Weight	2, 325 lb (1, 055 kg)
Fuel Capacity	48 US gallons (182 L)
