Piper PA-28-161 Maintenance Manual

PIPER AIRCRAFT, INC.
PA-28-161, WARRIOR III
MAINTENANCE MANUAL
PAGE 1
Nov 30/06
2J15
28-10-00
STORAGE
1. Fuel Tank
A. Removal
(1) Drain fuel from fuel tank. (See 12-10-00.)
(2) Remove tank assembly screws.
(3) Remove access panel at WS 54.00 and disconnect fuel line attached to tank.
(4) Pull tank from wing assembly enough to remove sender wire.
(5) Remove tank.
B. Installation
(1) Slide tank into position and connect sender wire.
(2) Slide tank completely into position and attach fuel line.
(3) Install and tighten screws around fuel tank.
(4) Fill fuel tank and check for leaks, unrestricted fuel flow, and proper quantity gauge readings.
Refer to fuel quantity sender/gauge check (installed).
(5) Position access plate and secure with screws.

Piper PA-28-161 Specifications

General

Manufacturer	Piper Aircraft
Model	PA-28-161 Warrior II
Engine	Lycoming O-320-D3G
Horsepower	160 hp
Seating Capacity	4
Wingspan	35 ft (10.7 m)
Length	24 ft 0 in
Maximum Speed	127 knots
Cruise Speed	122 knots
Maximum Takeoff Weight	2, 325 lb (1, 055 kg)
Fuel Capacity	48 US gallons (182 L)
