Piper PA-28-161 Maintenance Manual

PIPER AIRCRAFT, INC.
PA-28-161, WARRIOR III
MAINTENANCE MANUAL
PAGE 1
Nov 30/06
3G5
34 - CONTENTS
CHAPTER 34 - NAVIGATION AND PITOT / STATIC
TABLE OF CONTENTS
SUBJECT SECTION PA
GE GRID NO.
GENERAL 34-00-00 1 3G7
FLIGHT ENVIRONMENT DAT
A
34-10-00 1 3G9
Pitot / Static System 1 3G9
Vertical Speed Indicator 3 3G11
Description and Operation 3 3G11
Troubleshooting 3 3G11
Altimeter 43G12
Description and Operation 4 3G12
Troubleshooting 4 3G12
Airspeed Indicator 6 3G14
Description and Operation 6 3G14
Troubleshooting 6 3G14
Outside Air Temperature (OAT) Gauge 7 3G15
ATTITUDE AND DIRECTION 34-20-00 1 3H1
Attitude Deviation Indicator (ADI)/Artificial Horizon 1 3H1
Description and Operation 1 3H1
Troubleshooting 1 3H1
Standby Attitude Indicator 2 3H2
Electronic Flight Instrument System (EFIS) 3 3H3
Description 3 3H3
Maintenance 5 3H5
Component Locator 7 3H7
Directional Gyro 9 3H9
Description and Operation 9 3H9
Troubleshooting 12 3H12
Magnetic Heading Systems 13 3H13
King KCS-55A Slaving Compass (with HSI) 13 3H13
Flux Detector 13 3H13
Flux Detector Index Error 13 3H13
Slaving Control Compensator Check and Adjustment 14 3H14
S-TEC ST-180 Slaved Compass (with HSI) 15 3H15
Flux Detector 15 3H15
Magnetic Heading Compensation/Calibration 16 3H16
Magnetic Compass 18 3H18
Description and Operation 18 3H18
Troubleshooting 18 3H18
Adjustment 19 3H19
Magnetometer/OAT Sensor Assembly 19 3H19
Removal 19 3H19
Installation 19 3H19

Piper PA-28-161 Specifications

General

Manufacturer	Piper Aircraft
Model	PA-28-161 Warrior II
Engine	Lycoming O-320-D3G
Horsepower	160 hp
Seating Capacity	4
Wingspan	35 ft (10.7 m)
Length	24 ft 0 in
Maximum Speed	127 knots
Cruise Speed	122 knots
Maximum Takeoff Weight	2, 325 lb (1, 055 kg)
Fuel Capacity	48 US gallons (182 L)
