PIPER AIRCRAFT, INC.
PA-28-161, WARRIOR III
MAINTENANCE MANUAL
PAGE 7
Nov 30/06
5I21
91-33-10
Switch Lights
Figure 5 (Sheet 1 of 3)
A
D
B
C
F
SWITCH
LIGHTS
DIMMER
ASSY
L7B 20N
L7C 20
L7D 20
ELECTRICAL BUS
PANEL/SWITCH
LIGHTS
5K
2
1
7 1/2A
BATT
MASTER
ALT
LANDING
LIGHT
NAV
LIGHTS
STROBE
LIGHT
2
1
L7F 20N
(OPT)
PITOT
HEAT
L7G 20
L7H 20
FUEL
PUMP
RECOG
LIGHTS
PRIMER
2
1
L7E 20
85423 F
104295 F
L7A 20
