Piper PA-28-161 Maintenance Manual

PIPER AIRCRAFT, INC.
PA-28-161, WARRIOR III
MAINTENANCE MANUAL
PAGE 1
Nov 30/06
5J1
91-33-40
Navigation and Strobe Lights
Figure 1 (Sheet 1 of 2)
NAV LIGHTS
2
L1J20
2
L1B20
LEFT
WING
WHITE
POSITION
LIGHT
LEFT
NAV
LIGHT
1
BLUE
BLUE
3
2
RED
NAV
LIGHT
L1C20
11
3
NAV
LIGHTS
SWITCH
5A
21213
POWER
SUPPLY
1
BLUE
BLUE
3
3
2
L4B20
L1G20
L4C20
12
7
12
P2
R1
L4D20
R2
P1
12
2
1
1
2
3
L1A20
L4A20
ANTI-COLL LIGHTS
5A
L1F18
CAA20 (BLK)
WHITE
TAIL
LIGHT
OPTIONAL
STROBE
LIGHTS
SWITCH
85423 F
104295 F
WHITE
POSITION
LIGHT
RIGHT
NAV
LIGHT
GREEN
NAV
LIGHT
RIGHT
WING
STANDARD

Piper PA-28-161 Specifications

General

Manufacturer	Piper Aircraft
Model	PA-28-161 Warrior II
Engine	Lycoming O-320-D3G
Horsepower	160 hp
Seating Capacity	4
Wingspan	35 ft (10.7 m)
Length	24 ft 0 in
Maximum Speed	127 knots
Cruise Speed	122 knots
Maximum Takeoff Weight	2, 325 lb (1, 055 kg)
Fuel Capacity	48 US gallons (182 L)
