Piper PA-28-161 Maintenance Manual

PIPER AIRCRAFT, INC.
PA-28-161, WARRIOR III
MAINTENANCE MANUAL
PAGE 2
Nov 30/06
4K10
73-10-00
(7) Place a suitable container under disconnected primer line to catch discharged fuel. Operate
the pump to check for proper operation.
(8) If pump is operating satisfactorily, connect primer line inside engine compartment.
2. Prime Jets
A. Removal
(1) Disconnect the supply line from each jet.
(2) Using a deep socket, and light pressure, remove the jet from the cylinder.
B. Cleaning
CAUTION: DO NOT USE SHARP OBJECTS OR WIRE BRUSH TO CLEAN THE JET TUBE.
(1) Soak in carbon remover solution long enough to loosen any dirt.
(2) Blow clean with air pressure.
C. Installation
(1) Install the jet finger tight to assure that the threads are not crossed. Then torque to 60 inch-pounds.
(2) Align and install the fuel supply lines. Tighten to a snug fit.
NO
TE: If fuel stoppage of the primer system still exists after flushing, check the supply lines
for stoppage, bent or collapsed walls.

Piper PA-28-161 Specifications

General

Manufacturer	Piper Aircraft
Model	PA-28-161 Warrior II
Engine	Lycoming O-320-D3G
Horsepower	160 hp
Seating Capacity	4
Wingspan	35 ft (10.7 m)
Length	24 ft 0 in
Maximum Speed	127 knots
Cruise Speed	122 knots
Maximum Takeoff Weight	2, 325 lb (1, 055 kg)
Fuel Capacity	48 US gallons (182 L)
